Description
- Camera
- Image Sensor1/4″ progressive scan CMOS
- Min. IlluminationColor: 0.01 Lux @(F1.2, AGC ON), 0 Lux with IR
- Shutter Speed1/3 s to 1/100, 000 s, support slow shutter
- Wide Dynamic RangeDigital WDR
- Angle AdjustmentPan: 0° to 355°, tilt: 0° to 70°
- DNR3D DNR
- Day & NightIR cut filter with auto switch
- Lens
- Lens
2.8 , horizontal field of view 92°, 4 mm 2, horizontal field of view 74°
6 mm , horizontal field of view 49°
- Lens MountM12
- Illuminator
- IR RangeUp to 30 m
- Network
- Alarm TriggerVideo tampering, network disconnected, IP address conflicted
- ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour
- Video
- Max. Resolution1280 × 720
- Video Compression
Main stream: H.264
Sub stream: H.264/MJPEG
- H.264 TypeBaseline profile/Main profile
- Video Bit Rate32 Kbps to 2 Mbps
- Smart Feature-Set
- Basic EventMotion detection
- Image
- Image SettingBrightness, saturation, contrast, sharpness are adjustable via web browser or client software
- Day/Night SwitchSupport auto, scheduled
- Main Stream Max. Frame Rate
50Hz: 25fps @(1280 × 720)
60Hz: 30fps @(1280 × 720)
- OthersMirror, BLC (area configurable), region of interest (support 1 fixed region)
- Sub-stream Max. Frame Rate
50Hz: 25fps @(640 × 480, 352 × 288, 320 × 240)
60Hz: 30fps @(640 × 480, 352 × 240, 320 × 240)
- 4G
- StandardONVIF (PROFILE S), ISAPI
- Interface
- Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port
- General
- General FunctionOne-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark
- ResetSupport
- Startup and Operating Conditions-30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
- Power Supply12 VDC ± 25%, PoE (802.3af)
- Power Consumption and Current
12 VDC, 0.4 A, Max. 4.5 W
PoE (802.3af, 37 V to 57 V), 0.1 A to 0.16 A, Max. 6 W
- DimensionsΦ 111 mm × 82 mm (4.4″ × 3.2″)
- 500 g (1.1 lb.)
- Interface ProtectionIP67, IK10
